12m3 Concrete Transport Truck

 Drive type

 8x4 Mixer truck

 Cabin

 H3000 lengthened flat cab

 Equipments

 One sleeping bed, four-point suspension, A/C, Electric windows, desert   fliter

 Curb mass (kg)

 16000kgs

 Max capacity weight(kg)

 ≤50000kgs

 Dimension

 10250*2500*3870mm

 Wheel base(mm)

 1800+3775+1400

 Engine brand

 WEICHAI

 Engine model

 WP12NG380E51

 Power(hp)

 380HP

 Displacement(L)

 11.596L

 Max. torque/rpm

 1700 N.m/1200-1500rpm

 Emmission Standard

 Euro V

 Transmission

 FAST

 Model

 10JSD180

 Shifts

 10-forwards, 2-reverses, torque 1800Nm

 Clutch

 local brand

 Diameter(mm)

 Φ430

 Suspension

 Front Suspension

 Spring suspension

 Rear Suspension

 Spring suspension

 Front axle

 7500kg x2, MAN technology

 Rear axle

 16000kg×2, MAN Double reduction driven axle

 Ratio

 5.262

 Running brake

 Dual circuit compressed air brake

 Parking brake

 Rear wheel spring power brake

 Assistant brake

 Exhaust braking WEVB

 Tyres

 12.00R20 (12+1pcs)

 Tank capacity(L)

 8×140L

 Material

 ISO Standard Cylinder/ECE Standard Solenoid Valve Cylinder Valve/ISO   Standard Pipeline/Double Gasification Integrated Gas Tank

 MIXER TANQUE

 12CBM

 Reducer : Bonfiglioli 580L

 Pump : Eaton 64

 Motor : Eaton 64

 Radiator (26L), 450 liters water tank, air pressure water supply, 3-point   linkage control mechanism, screw down chute operating mechanism, two   sets of high and low pressure flushing devices, one integrated rear   combined waterway and a toolbox (730 * 345 * 310mm ),ladder
